GENERAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
10 to +40oC |
Operating Humidity |
0 to 85% RH |
|
Storage Temperatures |
-20 to +70oC |
Storage Humidity |
5 to 90% RH |
|
Hi-Pot Test |
MTBF |
||
|
Hi-Pot |
3000V AC |
MTBF |
50,000Hours at 25oC |
|
EMISSSION |
SAFETY |
||
|
EMI/EMC |
FCC |
Safety Approvals |
UL/CUL/GS/CCC/ |
|
Safety Compliant |
UL 60950/EN 60950/ |
||
|
ELECTRICAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Input |
Output |
||
|
Input Voltage Range |
90-264V AC |
Output Voltage |
5V DC |
|
Input Frequency |
47-63Hz |
Output Current |
5A(40.5VA max) |
|
Input Current |
1A(max) |
Output Tolerance |
5% |
|
|
|
Ripple & Noise |
1%p-p max |
|
|
|
Efficiency |
>75% |
OUTPUT SPECIFICATIONS
SERIES NO. : IEC36
SWITCHING ADAPTOR
DESKTOP-INLET SOCKET
36 SERIES
PART NO. |
OUTPUT |
|
VOLT |
CURRENT |
|
IEC36-0503000 |
5.0V |
3.00A |
IEC36-0504000 |
5.0V |
4.00A |
IEC36-0505000 |
5.0V |
5.00A |
IEC36-0603000 |
6.0V |
3.00A |
IEC36-0604000 |
6.0V |
4.00A |
IEC36-0604500 |
6.0V |
4.50A |
IEC36-0752000 |
7.5V |
2.00A |
IEC36-0853000 |
7.5V |
3.00A |
IEC36-0754000 |
7.5V |
4.00A |
IEC36-0802000 |
8.0V |
2.00A |
IEC36-0802500 |
8.0V |
2.50A |
IEC36-0803000 |
8.0V |
3.00A |
IEC36-0902000 |
9.0V |
2.00A |
IEC36-0902500 |
9.0V |
2.50A |
IEC36-0903000 |
9.0V |
3.00A |
IEC36-0904000 |
9.0V |
4.00A |
IEC36-1002000 |
10.0V |
2.00A |
IEC36-1003000 |
10.0V |
3.00A |
IEC36-1201500 |
12.0V |
1.50A |
IEC36-1202000 |
12.0V |
2.00A |
IEC36-1202500 |
12.0V |
2.50A |
IEC36-1203000 |
12.0V |
3.00A |
 |
 |
 |
 |
 |
 |
