| ELECTRICAL SPECIFICATIONS |
|||
|---|---|---|---|
| Input |
Output |
||
Input Voltage Range |
90-264V AC |
Output Voltage |
5 - 48V DC |
Input Frequency |
47-63Hz |
Output Current |
8A(65VA max) |
Input Current |
1.5A(max) |
Output Tolerance |
5% |
|
|
|
Ripple & Noise |
2% mV p-p max |
|
|
|
Efficiency |
>80% |
OUTPUT SPECIFICATIONS
SERIES NO. : CB65
SWITCHING ADAPTOR
DESKTOP-CORD IN/OUT
65 SERIES
PART NO. |
OUTPUT |
|
VOLT |
CURRENT (max) |
|
CB65-0508000 |
5.0V |
8.00A |
CB65-0558000 |
5.5V |
8.00A |
CB65-0608000 |
6.0V |
8.00A |
CB65-0658000 |
6.5V |
8.00A |
CB65-0706000 |
7.0V |
6.00A |
CB65-0756000 |
7.5V |
6.00A |
CB65-0806000 |
8.0V |
6.00A |
CB65-0856000 |
8.5V |
6.00A |
CB65-0906000 |
9.0V |
6.00A |
CB65-0956000 |
9.5V |
6.00A |
CB65-1006000 |
10.0V |
6.00A |
CB65-1056000 |
10.5V |
6.00A |
CB65-1105900 |
11.0V |
5.90A |
CB65-1155650 |
11.5V |
5.65A |
CB65-1205410 |
12.0V |
5.41A |
CB65-1255200 |
12.5V |
5.20A |
CB65-1305000 |
13.0V |
5.00A |
CB65-1354810 |
13.5V |
4.81A |
CB65-1404640 |
14.0V |
4.64A |
CB65-1454480 |
14.5V |
4.48A |
CB65-1504330 |
15.0V |
4.33A |
CB65-1554190 |
15.5V |
4.19A |
CB65-1604060 |
16.0V |
4.06A |
CB65-1653930 |
16.5V |
3.93A |
CB65-1703820 |
17.0V |
3.82A |
CB65-1753710 |
17.5V |
3.71A |
CB65-1803610 |
18.0V |
3.61A |
CB65-1853510 |
18.5V |
3.51A |
CB65-1903420 |
19.0V |
3.42A |
CB65-1953330 |
19.5V |
3.33A |
CB65-2003250 |
20.0V |
3.25A |
CB65-2053170 |
20.5V |
3.17A |
CB65-2103090 |
21.0V |
3.09A |
CB65-2153020 |
21.5V |
3.02A |
CB65-2202950 |
22.0V |
2.95A |
CB65-2252880 |
22.5V |
2.88A |
CB65-2302820 |
23.0V |
2.82A |
CB65-2352760 |
23.5V |
2.76A |
CB65-2402700 |
24.0V |
2.70A |
CB65-2452650 |
24.5V |
2.65A |
CB65-2502600 |
25.0V |
2.60A |
CB65-2552540 |
25.5V |
2.54A |
CB65-2602500 |
26.0V |
2.50A |
PART NO. |
OUTPUT |
|
VOLT |
CURRENT (max) |
|
CB65-2652450 |
26.5V |
2.45A |
CB65-2702400 |
27.0V |
2.40A |
CB65-2752360 |
27.5V |
2.36A |
CB65-2802320 |
28.0V |
2.32A |
CB65-2852280 |
28.5V |
2.28A |
CB65-2902240 |
29.0V |
2.24A |
CB65-2952200 |
29.5V |
2.20A |
CB65-3002160 |
30.0V |
2.16A |
CB65-3052130 |
30.5V |
2.13A |
CB65-3102090 |
31.0V |
2.09A |
CB65-3152060 |
31.5V |
2.06A |
CB65-3202030 |
32.0V |
2.03A |
CB65-3252000 |
32.5V |
2.00A |
CB65-3301960 |
33.0V |
1.96A |
CB65-3351940 |
33.5V |
1.94A |
CB65-3401910 |
34.0V |
1.91A |
CB65-3451880 |
34.5V |
1.88A |
CB65-3501850 |
35.0V |
1.85A |
CB65-3551830 |
35.5V |
1.83A |
CB65-3601800 |
36.0V |
1.80A |
CB65-3651780 |
36.5V |
1.78A |
CB65-3701750 |
37.0V |
1.75A |
CB65-3751730 |
37.5V |
1.73A |
CB65-3801710 |
38.0V |
1.71A |
CB65-3851680 |
38.5V |
1.68A |
CB65-3901660 |
39.0V |
1.66A |
CB65-3951640 |
39.5V |
1.64A |
CB65-4001620 |
40.0V |
1.62A |
CB65-4051600 |
40.5V |
1.60A |
CB65-4101580 |
41.0V |
1.58A |
CB65-4151560 |
41.5V |
1.56A |
CB65-4201540 |
42.0V |
1.54A |
CB65-4251520 |
42.5V |
1.52A |
CB65-4301510 |
43.0V |
1.51A |
CB65-4351490 |
43.5V |
1.49A |
CB65-4401470 |
44.0V |
1.47A |
CB65-4451460 |
44.5V |
1.46A |
CB65-4501440 |
45.0V |
1.44A |
CB65-4551420 |
45.5V |
1.42A |
CB65-4601410 |
46.0V |
1.41A |
CB65-4651390 |
46.5V |
1.39A |
CB65-4701380 |
47.0V |
1.38A |
CB65-4751360 |
47.5V |
1.36A |
CB65-4801350 |
48.0V |
1.35A |
|
GENERAL SPECIFICATIONS |
|||
|---|---|---|---|
|
Temperatures |
Humidity |
||
|
Operating Temperatures |
0 to +40oC |
Operating Humidity |
15 to 95% RH |
|
Storage Temperatures |
-20 to +70oC |
Storage Humidity |
5 to 95% RH |
|
Hi-Pot Test |
MTBF |
||
|
Hi-Pot |
3000V AC/10mA/3S |
MTBF |
30,000Hours at 25oC |
|
EMISSION |
SAFETY |
||
|
EMI/EMC |
EMC |
Safety Approvals |
CE/CB |
|
GREEN POWER |
Safety Compliant |
EN 60950 |
|
|
ErP |
|||
 |
 |
 |
 |
 |
 |
